Overview

Ultra-Slimline Cor Vision Sliding Door

20mm sightline.

We’re proud to introduce the most demanding new generation Cor Vision 20mm ultra-slim aluminium sliding patio door by Cortizo, giving you the most unique bonded glazing solution in the market at the best price.

Unique Engineering

Boasting Ultra-Slim Sleek Sightlines.

This Cor Vision sliding door is made from premium grade aluminium and is structurally bonded from the glass to the frame. It has been specifically designed to ensure the frame is completely concealed by the external and internal wall, less frame and more natural light makes for a truly breathtaking spectacle.

This effortlessly stunning look is very much on-trend in the luxury housing market, demanding the slimmest possible frames coupled with large expanses of glass.

Low U-Value

U value of only 1.2/wm2k.

High Performance Runners

Heavy-duty stainless steel 4 runners per sliding panel.

Minimal Sightline

20mm vertical profile sightline.

Intergrated Handle

Handle is Integrated in Sash profile.

Key Features

  • We can achieve less visible frame and more glass by using the Corvision structurally bonded system.
  • Our Corvision systems are the slimmest sliding door in the market place.
  • Due to this unique slimline outer frame system you have the ability to install our Corvision sliding doors into your existing properties or new extensions without having to plan it into the initial construction design.
  • Each glass panel can be maximum 2500mm width and 3000mm height.
  • Manufactured in-house by our experienced and professional manufacturers.
  • Maximum weight of each panel. 320 Kg.
  • Yale PAS 24 locking cylinders.

Technical Detail

  • Maximum glazing thickness: 32mm
  • Maximum width of a sash (L) = 2500mm
  • Maximum height of a sash (H) = 3000mm
  • Maximum weight single sash: 320Kg
  • Acoustic insulation: Maximum glazing 41 DB.
  • Water tightness: (EN 12208:200) Class 7A
  • Wind resistance: (EN 12210:2000) Class C5
  • Thermal insulation: Uw from 1.2 (W/m2K)
  • Reference test 1,23 x 1,55m, 1 sash + 1 fixed lights.

Configuration

Strong & Secure

We understand security is important; that’s why our products are designed with a combination of aesthetics and safety. We use PAS 24 laminated toughened glass, and high security locking system. Ensuring the best security standards with unique Yale PAS24 Cylinders which is one of the most secure revolutionary locking systems, approved by the police and has achieved the highest kitemark star rating. For any questions regarding security improvements in your household, please contact our team.

Contact

Quality Check

We are proud to have our own manufacturing facility, and take full accountability for the quality of our products, offering industry-leading 20-year guarantee with every installation. Our success is built on quality with no compromise, management of lead times, advanced machinery, highly trained engineering, and ensuring all products go through rigorous quality testing, giving you peace of mind that you’re choosing something that is built to last.

Contact

Choose Your Colour

We offer four standard colour options: Black, white, anthracite grey, and anthracite grey textured, as well as a huge selection of 200+ RAL colours.

We can cater for any colour requirements you may have, even if your colour is not available on the 200+ RAL options, we would be happy to assist you in finding your ideal colour to perfectly fit your requirements.

Contact
Cor Vision Free way

Smart Free way Level Cros.

Cortizo recently introduced the invisible track feature in the cor vision doors to achieve a smart free way level crossing threshold by concealing track under the floor as part of the finish floor to provide a seamless threshold inside and out while offering a simple and elegant solution.
